Muncie CS8 Series PTO Units

The Muncie CS8 is Muncie's clutch shift PTO on an SAE 8-bolt mounting. It shares its parts list and service manual with the 6-bolt Muncie CS6 Series and the CB6 and CB8 clutch brake models. A CS unit has a standard drag brake; a CB unit adds an optional shaft brake.

CS8 Series features

• SAE 8-bolt mountings: standard, metric, non-standard, low profile rear and deep.
• Transmission gears are listed for Aisin, Jatco, Allison, Clark/Fuller, Fuller, Mack, Mercedes, Spicer and Universal applications.
• Shifters include 12 or 24 volt manual air, 12 or 24 volt electric/air, and 12 or 24 volt electric/hydraulic, with Ram and GM 4500 to 6500 (2019 and later) versions.
• Options include pressure lube and a pulse generator.
• Outputs include a 1-1/4 inch round shaft, a 1410 companion flange, SAE A, B, BB and C pump flanges, and DIN 5462.
• A 1.44:1 speed ratio is offered on 8-bolt units only.

Find your exact unit

Start with the full model number on your PTO. A CS model number reads: CS, the mounting (8S is the SAE 8-bolt standard mount), the transmission gear designator, the speed ratio, then after the dash the shifter, assembly arrangement, output and special feature. For example, CS8S-M6509-A3EX is an 8-bolt standard mount with the Mack M65 gear, the 09 ratio, 12 volt manual air shift and an SAE C output.

For repairs, use our Muncie CS8 Series parts list and service manual or shop all Muncie PTO parts. Compare the CS8 with the Muncie CS6 Series, the Muncie TG8 Series and the Muncie 82 Series, or browse all Muncie PTO series. Not sure which unit fits? Call us toll free at (877) 776-4600 and we will match a PTO to your transmission and application.
