Muncie F20 Series PTO F20-F1312-GS51XPX - Ford 10-Speed 10R140
Muncie Ford 10 Speed Model PTO P/N: F20-F1312-GS51XPX or F20F1312GS51XPX

List Price: $5,916.71
Our Price: $5,215.96
Sale Price: $4,515.19
Savings: $1,401.52
CONDITION: New


Availability: Usually Ships in 3 to 5 Business Days
Product Code: 3053-F20F1312GS51XPX
Qty:

Description Technical Specs Extended Information

The Muncie F20-F1312-GS51XPX or F20F1312GS51XPX is a solenoid-activated power take-off unit built for Ford Super Duty trucks F-250 through F-600 equipped with the Ford 10R140 10-speed automatic transmission. The F20 Series carries an internal speed ratio code of 12, delivering 130% of engine speed with an intermittent rating of 50 HP at 1,000 RPM and 261 lb-ft of intermittent torque. It ships with a pre-configured wiring harness and is available in direct-mount or round shaft output configurations. Patent-pending noise abatement technology is built in. An optional Muncie Start electronically controlled, modulated clutch engagement system can be specified to eliminate torque spikes on startup for high-inertia loads. A genuine Muncie Power Products part, sold by Pro Gear and Transmission. Call us to confirm the correct output configuration for your application.
Features
  • Fits Ford Super Duty F-250 through F-600 with Ford 10R140 10-speed automatic transmission Solenoid activated engagement Internal speed ratio code 12 - 130% of engine speed Intermittent rating: 50 HP at 1,000 RPM, 261 lb-ft torque Patent-pending noise abatement technology built in Available with Muncie Start modulated clutch engagement system for high-inertia load applications
